本文共 5961 字，大约阅读时间需要 19 分钟。

一、xxl-job-admin

①执行数据库脚本tables_xxl_job.sql，生成库表

②通过nginx为调度中心集群做负载均衡，分别启动8001和8002端口的xxl-job-admin实例，建议修改xxl-job-admin的打包方式，将配置文件application.properties从jar包中剥离出来，方便修改配置

application.properties

### webserver.port=8001server.context-path=/xxl-job-admin### resourcesspring.mvc.static-path-pattern=/static/**spring.resources.static-locations=classpath:/static/### freemarkerspring.freemarker.templateLoaderPath=classpath:/templates/spring.freemarker.suffix=.ftlspring.freemarker.charset=UTF-8spring.freemarker.request-context-attribute=requestspring.freemarker.settings.number_format=0.############# mybatismybatis.mapper-locations=classpath:/mybatis-mapper/*Mapper.xml### xxl-job, datasourcespring.datasource.url=jdbc:mysql://192.168.124.129:3306/xxl-job?Unicode=true&characterEncoding=UTF-8spring.datasource.username=rootspring.datasource.password=123456spring.datasource.driver-class-name=com.mysql.jdbc.Driverspring.datasource.type=org.apache.tomcat.jdbc.pool.DataSourcespring.datasource.tomcat.max-wait=10000spring.datasource.tomcat.max-active=30spring.datasource.tomcat.test-on-borrow=true### xxl-job emailspring.mail.host=smtp.qq.comspring.mail.port=25spring.mail.username=xxxxxx@qq.com###填的是SMTP授权码,不是邮箱密码spring.mail.password=xxxxxxspring.mail.properties.mail.smtp.auth=truespring.mail.properties.mail.smtp.starttls.enable=truespring.mail.properties.mail.smtp.starttls.required=true### xxl-job loginxxl.job.login.username=adminxxl.job.login.password=123456### xxl-job, access tokenxxl.job.accessToken=myAccessToken### xxl-job, i18n (default empty as chinese, "en" as english)xxl.job.i18n=

③配置并启动Nginx

http {       upstream xxl{	 server 192.168.124.129:8001;         server 192.168.124.129:8002;    }    server{        listen       8088;         location / {            proxy_pass  http://xxl;        }    }}

③成功后，我们可以通过nginx来访问xxl-job-admin集群了

http://192.168.124.129:8088/xxl-job-admin

配置执行器和任务

路由策略置为轮询，cron表达式设置为每五秒调度一次

二 、执行器项目

新建执行器项目XXL-Task，pom.xml文件引入依赖，似乎存在与SpringBoot版本不兼容的情况，启动会报异常，此处采用的SpringBoot版本为1.5.18.RELEASE



     org.springframework.boot


     spring-boot-starter-parent


     1.5.18.RELEASE





     com.xuxueli


     xxl-job-core


     2.0.1



application.properties文件（Appname类比MQ的Group）

server.port=9001#xxl-job调度中心工程的地址xxl.job.admin.addresses=http://192.168.124.129:8088/xxl-job-admin #xxl-job executorxxl.job.executor.appname=testAppNamexxl.job.executor.ip=xxl.job.executor.port=9999#xxl-job log path xxl.job.executor.logpath=/data/applogs/xxl-job/jobhandler#xxl-job, access token xxl.job.accessToken=myAccessToken#执行器Log文件定期清理功能，指定日志保存天数，日志文件过期自动删除。限制至少保持3天，否则功能不生效xxl.job.executor.logretentiondays=-1

XxlJobConfig

package com.yj.config;import org.springframework.beans.factory.annotation.Value;import org.springframework.context.annotation.Bean;import org.springframework.context.annotation.ComponentScan;import org.springframework.context.annotation.Configuration;import com.xxl.job.core.executor.impl.XxlJobSpringExecutor;@Configuration@ComponentScan(basePackages = "com.yj.handler")public class XxlJobConfig {	@Value("${xxl.job.admin.addresses}")	private String adminAddresses;	@Value("${xxl.job.executor.appname}")	private String appName;	@Value("${xxl.job.executor.ip}")	private String ip;	@Value("${xxl.job.executor.port}")	private int port;	@Value("${xxl.job.accessToken}")	private String accessToken;	@Value("${xxl.job.executor.logpath}")	private String logPath;	@Value("${xxl.job.executor.logretentiondays}")	private int logRetentionDays;	@Bean(initMethod = "start", destroyMethod = "destroy")	public XxlJobSpringExecutor xxlJobExecutor() {		XxlJobSpringExecutor xxlJobSpringExecutor = new XxlJobSpringExecutor();		xxlJobSpringExecutor.setAdminAddresses(adminAddresses);		xxlJobSpringExecutor.setAppName(appName);		xxlJobSpringExecutor.setIp(ip);		xxlJobSpringExecutor.setPort(port);		xxlJobSpringExecutor.setAccessToken(accessToken);		xxlJobSpringExecutor.setLogPath(logPath);		xxlJobSpringExecutor.setLogRetentionDays(logRetentionDays);		return xxlJobSpringExecutor;	}}

MyJobHandler

package com.yj.handler;import org.slf4j.Logger;import org.slf4j.LoggerFactory;import org.springframework.beans.factory.annotation.Value;import org.springframework.stereotype.Component;import com.xxl.job.core.biz.model.ReturnT;import com.xxl.job.core.handler.IJobHandler;import com.xxl.job.core.handler.annotation.JobHandler;import com.xxl.job.core.log.XxlJobLogger;@JobHandler(value = "myJobHandler")@Componentpublic class MyJobHandler extends IJobHandler {		private static final Logger log = LoggerFactory.getLogger(MyJobHandler.class);	@Value("${server.port}")	private String port;		@Override	public ReturnT

     execute(String param) throws Exception {		XxlJobLogger.log("Hello World,port:"+port);		log.info("Hello World,port:"+port);		return SUCCESS;	}}


分别启动server.port=9001,9002端口的执行器实例，其中,xxl.job.executor.port=9999,9998，xxl.job.executor.appname都为testAppName

启动后在xxl-job-admin控制台（有点类似Eureka）已经能看到注册成功的执行器实例了

 查看执行器控制台日志，发现xxl-job-admin对9001和9002的XXL-Task项目进行了负载均衡的调度（类比MQ集群模式）

15:00:53.254 logback [Thread-28] INFO  com.yj.handler.MyJobHandler - Hello World,port:900215:00:58.284 logback [Thread-16] INFO  com.yj.handler.MyJobHandler - Hello World,port:900115:01:03.261 logback [Thread-28] INFO  com.yj.handler.MyJobHandler - Hello World,port:9002

我们再将路由策略置为分片广播的模式（类比MQ广播模式）

15:14:43.277 logback [Thread-28] INFO  com.yj.handler.MyJobHandler - Hello World,port:900215:14:48.281 logback [Thread-28] INFO  com.yj.handler.MyJobHandler - Hello World,port:900215:14:53.264 logback [Thread-28] INFO  com.yj.handler.MyJobHandler - Hello World,port:900215:14:43.343 logback [Thread-26] INFO  com.yj.handler.MyJobHandler - Hello World,port:900115:14:48.299 logback [Thread-26] INFO  com.yj.handler.MyJobHandler - Hello World,port:900115:14:53.340 logback [Thread-26] INFO  com.yj.handler.MyJobHandler - Hello World,port:9001

我们再验证下邮件的报警功能，在执行器任务中抛出一个异常int i=1/0，会收到告警邮件
